AGV Kit sales

CarryBee basic units can be oprvided.Customer buld these KIT onto own carrier,and make up AGV.

CarryBee basic units can be provided.Customer builds this KIT onto own carrier,and makes up complete AGV.

CarryBee basic units can be oprvided.Customer buld these KIT onto own carrier,and make up AGV.

Control（Ref.１） Programable(Absolute､Count up)/No programable(Tape cut,Spot marker stop,Marker pattern)
Transportable weight Towing :200,400,500,750, 1000, 1500kg Loading : 100, 200, 400, 500,750kg
Guidasnce method Optical,<Magnetic>,<Optical&Macnetic>
Drive method ～Towing 1000kg (Loading 500kg) :2WD,Towing 1500kg (Loading 750kg) :4WD
Driving speed ～Approx27m/min <Corresponding up to 60m/min is possible.>
Length×Width×Height -
Minimum turning radius ～Towing 1000kg (Loading 500kg) : R550mm, Towing 1500kg(Loading 750kg) :R700mm (Ref.2)
Continuously operable time 8Hr(Depend on operating rate and battery size)
Function/equipment
Driving function
<Driving speed 4speeds changeable>
Programing function
100 programs､256 stations､Moving mode(Straight,Right turn,Left turn,Stop,Speed change,Obstacle sensor ON/OFF,etc )<Setting 99 moving mode is possible.>,<Traffic control at intersection or confluence>,<Optical communication>,<Remote controle>
Safty function
Overload detection,Obstacle sensor<Detecting area variable obstacle sensor (PBS type>,Emergency stop switch,Emergency warning sound<Signal tower>,<Bumper sensor>,<Melody unit>
Other
Driving wheel free mechanism when manual operation,<Towing hook>,<Automatic detachable hook,>,<Battery>,<Battery charger>

(Ref.1)There are functions "No programable type"can't select.

(Ref.2)In case of same body size as Simple cart type

< >:Option
